Welcome to
DCPowerJacks.net
We are located in Denver
Colorado and are committed to the satisfaction of our customers for over 5
years. Supplying DC Power Jacks, Connectors and Sockets at the most reasonable prices on the
internet is what has keep us around. Manufacturers would have you replace your whole system board at anywhere from $200-$800 instead of replacing a broken DC
Jack. Purchase the DC Jack you need, repair your laptop, or whatever device your
working on, yourself and save hundreds of dollars. Please browse the site for items of interest and if you don't see what your looking for please email us
using the contact us forum within the web site.
Click here to enter our online store or scroll down and click the model number below to go directly to the item you need
DC Power Jack, Part #PJ001
Available in center pin sizes 1.65, 2.0 and 2.5mm
The optional Shield for this Jack is included in case you need it, if not simply remove it.
Acer Travelmate: 220, 230, 330, 332T, 370, 732, 734, 1350, 1360
Alienware: Area 51 Sentia
Compaq EVO: N110, N150, N180, N200, N400, N410, N600, N610, N620, N800, N800C, N800W, N800V
Compaq Armada: 100, 110, V300, E500, E500S, E700
Compaq Prosignia: 190SMB
Compaq Presario: 2800, 2800CA, 2800T, 2835CA
HP Pavilion ZE49xx series: ZE4900, ZE4901,
ZE4902, ZE4903, ZE4904, ZE4905, ZE4906, ZE4907, ZE4908, ZE4909, ZE4910,
ZE4911, ZE4912, ZE4915, ZE4918, ZE4920, ZE4922, ZE4923, ZE4925, ZE4926,
ZE4927, ZE4928, ZE4929, ZE4930, ZE4935, ZE4940, ZE4945, ZE4950, ZE4955,
ZE4960, ZE4965, ZE4970, ZE4974, ZE4975, ZE4980
Gateway: 600YGR/600YG2
Gateway Solo: 1200, 1400, 1450, 9500, 9550
Compaq Presario: 1000, 1010, 1020, 1030, 1060, 1065, 1070, 1072, 1075, 1080, 1090, 1090es, 1110
Compaq Presario:* 1200, 1207, 1210, 1215, 1220es, 1230, 1232es, 1234, 1235, 1236, 1237, 1238, 1240, 1242, 1244, 1245, 1246, 1247, 1250, 1252, 1255, 1256, 1260, 1266, 1267, 1270, 1272, 1273, 1274, 1275, 1277, 1278, 1279
Compaq Presario: 12XL, 1200XL119, 1200XL450, 12XL101, 12XL103, 12XL104, 12XL105, 12XL106, 12XL112, 12XL113, 12XL114, 12XL118, 12XL125
Compaq Presario:* 16XL, 1600, 1600s, 1600l, 1610, 1611, 1615, 1620, 1621, 1622, 1624, 1625, 1626, 1630, 1635, 1636, 1640, 1650, 1655, 1660, 1670, 1675, 1680, 1681, 1683, 1685, 1687, 1688, 1690, 1692, 1693, 1694
Compaq Presario:* 1800, 1805, 1810
Compaq Presario: 2100 Series, 2500 Series, most 2700 Series
Compaq Prosignia 150 SMB
Compaq Business Notebook NX9005, NX9008, NX9010
* Compaq is known to use several different types of DC Jacks for these models, personal verification should be done prior to purchase.
HP Omnibook XE series, XE2, 6000 Series
XE4100, XE4500, 6000
HP Pavilion XZ series XZ133, XZ148, XZ163, XZ168, XZ275, XZ295, XZ335, ZX355
HP Pavilion XF series XF125, XF145, XF235, XF255, XF315, XF325, XF328, XF335
HP Pavilion XT series XT115, XT118, XT125, XT128, XT155, XT178, XT183, XT188, XT200, XT236, XT276, XT345, XT375, XT395, XT412, XT500, XT512, XT545, XT555, XT565, XT575, XT585, XT595, XT4345QV, XT4316WM, XT4328CL, XT4345QV, XT5335QV, XT5366WM, XT5377QV, XT5477WM
HP Pavilion N series N3000, N3100, N3110, N3150, N3190, N3200, N3210, N3215, N3250, N3270, N3290, N3295, N3300, N3310, N3330, N3350, N3370, N3390, N3400, N3402, N3410, N3438, N3478, N3490
HP Pavilion ZT series ZT1172, ZT1182
HP Pavilion ZE series ZE1000, ZE1100, ZE1115, ZE1145, ZE1200, ZE1201, ZE1202, ZE1210, ZE1230, ZE1235, ZE1250, ZE1260 ZE4000, ZE4200, ZE4100, ZE4935, ZE4400, ZE4100, ZE4101, ZE4102, ZE4103S, ZE4105S, ZE4111S, ZE4115, ZE4120S, ZE4123, ZE4123S, ZE4125, ZE4130, ZE4133, ZE4140, ZE4145, ZE4200, ZE4201, ZE4204, ZE4207, ZE4208, ZE4209, ZE4210, ZE4211, ZE4212, ZE4214, ZE4218, ZE4219, ZE4220, ZE4221, ZE4222, ZE4222AP, ZE4224, ZE4228, ZE4229, ZE4230, ZE4231, ZE4232, ZE4234, ZE4236, ZE4239, ZE4240, ZE4241, ZE4251, ZE4257EA, ZE4258, ZE4261, ZE4262, ZE4268, ZE4271, ZE4274, ZE4278, ZE4281, ZE4282, ZE4284, ZE4288, ZE4292, ZE4294, ZE4298, ZE4300, ZE4301, ZE4302, ZE4305EA, ZE4306WM, ZE4307LA, ZE4308EA, ZE4310, ZE4310EA, ZE4311, ZE4312, ZE4313, ZE4314, ZE4315, ZE4315CA, ZE4315US, ZE4316, ZE4317, ZE4317EA, ZE4318, ZE4318EA, ZE4319, ZE4320EA, ZE4321, ZE4321EA, ZE4322EA, ZE4323EA, ZE4325CA, ZE4325EA, ZE4325US, ZE4326, ZE4328US, ZE4332EA, ZE4333EA, ZE4334EA, ZE4335EA, ZE4335US, ZE4336EA, ZE4345EA, ZE4345US, ZE4347EA, ZE4348EA, ZE4349EA, ZE4351EA, ZE4352EA, ZE4353EA, ZE4354EA, ZE4355EA, ZE4355US, ZE4356EA, ZE4357EA, ZE4358US, ZE4360EA, ZE4365US, ZE4367EA, ZE4375EA, ZE4384EA, ZE4385EA, ZE4386EA, ZE4400, ZE4400, ZE4401US, ZE4402US, ZE4403EA, ZE4404EA, ZE4405EA, ZE4407EA, ZE4408EA, ZE4409EA, ZE4410AK, ZE4410AP, ZE4410CA, ZE4410EA, ZE4411AP, ZE4412AP, ZE4413AP, ZE4414AP, ZE4414EA, ZE4415AP, ZE4415EA, ZE4416AP, ZE4416EA, ZE4417EA, ZE4420CA, ZE4420US, ZE4423EA, ZE4424EA, ZE4424US, ZE4425EA, ZE4427WM, ZE4428EA, ZE4430US, ZE4453EA, ZE4454EA, ZE4455EA, ZE4500, ZE4500, ZE4501US, ZE4502US, ZE4504EA, ZE4505EA, ZE4507EA, ZE4508EA, ZE4509EA, ZE4510AP, ZE4510EA, ZE4510OM, ZE4511EA, ZE4512EA, ZE4513EA, ZE4514EA, ZE4516EA, ZE4518EA, ZE4519EA, ZE4520AP, ZE4520EA, ZE4521AP, ZE4521EA, ZE4522AP, ZE4522EA, ZE4523AP, ZE4523EA, ZE4524EA, ZE4525EA, ZE4525US, ZE4526EA, ZE4530US, ZE4540CA, ZE4540US, ZE4545US, ZE4546SR, ZE4547WM, ZE4550ST, ZE4560US, ZE4565QV, ZE4600, ZE4600, ZE4601US, ZE4603EA, ZE4604EA, ZE4605EA, ZE4610EA, ZE4610US, ZE4612EA, ZE4614EA, ZE4615EA, ZE4630US, ZE4710EA, ZE4715EA, ZE4717EA, ZE4718EA, ZE4719EA, ZE4725EA, ZE4728EA, ZE4800 CTO, ZE4801EA, ZE4803US, ZE4805US, ZE4805WM, ZE4810US, ZE4815EA, ZE4819EA, ZE4820EA, ZE4821EA, ZE4828EA, ZE5000, ZE5100, ZE5155, ZE5160, ZE5165, ZE5170, ZE5185, ZE5190, ZE5200, ZE5207, ZE5217, ZE5228, ZE5232, ZE5236, ZE5238, ZE5240, ZE5242, ZE5244, ZE5250, ZE5252, ZE5258, ZE5262, ZE5270, ZE5279, ZE5300, ZE5307LA, ZE5315EA, ZE5320AP, ZE5320EA, ZE5325EA, ZE5339EA, ZE5343EA, ZE5344EA, ZE5345EA, ZE5345US, ZE5354EA, ZE5357LA, ZE5360EA, ZE5362EA, ZE5365US, ZE5375US, ZE5385CA, ZE5385US, ZE5395US, ZE5400, ZE5407LA, ZE5410AP, ZE5413EA, ZE5414EA, ZE5415AP, ZE5415EA, ZE5416EA, ZE5417LA, ZE5418EA, ZE5420EA, ZE5425EA, ZE5426EA, ZE5427LA, ZE5430EA, ZE5440EA, ZE5443EA, ZE5445EA, ZE5446EA, ZE5447LA, ZE5451US, ZE5457LA, ZE5460EA, ZE5460US, ZE5462EA, ZE5467LA, ZE5468CL, ZE5470US, ZE5475CA, ZE5477LA, ZE5477WM, ZE5478CL, ZE5490US, ZE5497LA, ZE5500, ZE5501US, ZE5504EA, ZE5505EA, ZE5506EA, ZE5507EA, ZE5510AP, ZE5510EA, ZE5511AP, ZE5511EA, ZE5512AP, ZE5512EA, ZE5513AP, ZE5514AP, ZE5515AP, ZE5515EA, ZE5516AP, ZE5516EA, ZE5517AP, ZE5517EA, ZE5518AP, ZE5519AP, ZE5519EA, ZE5520EA, ZE5521AP, ZE5521EA, ZE5522AP, ZE5523AP, ZE5523EA, ZE5524AP, ZE5524EA, ZE5525AP, ZE5525EA, ZE5526AP, ZE5526EA, ZE5527EA, ZE5528EA, ZE5529EA, ZE5530EA, ZE5531EA, ZE5532EA, ZE5533EA, ZE5534EA, ZE5535EA, ZE5537LA, ZE5547WM, ZE5560US, ZE5565QV, ZE5568CL, ZE5570US, ZE5575SR, ZE5580US, ZE5587LA, ZE5590US, ZE5600, ZE5601AP, ZE5601EA, ZE5602AP, ZE5602EA, ZE5602US, ZE5603AP, ZE5603EA, ZE5604AP, ZE5604EA, ZE5604RS, ZE5605AP, ZE5605EA, ZE5605SR, ZE5607EA, ZE5607WM, ZE5608AP, ZE5609AP, ZE5609EA, ZE5610AP, ZE5610CA, ZE5610EA, ZE5611AP, ZE5611EA, ZE5612AP, ZE5612EA, ZE5613AP, ZE5613EA, ZE5614AP, ZE5614EA, ZE5615AP, ZE5615CA, ZE5615EA, ZE5615SR, ZE5616AP, ZE5616EA, ZE5617AP, ZE5617EA, ZE5617WM, ZE5618EA, ZE5619EA, ZE5620EA, ZE5620US, ZE5622EA, ZE5623EA, ZE5624EA, ZE5626EA, ZE5630US, ZE5631EA, ZE5635EA, ZE5636EA, ZE5637LA, ZE5638EA, ZE5640EA, ZE5645EA, ZE5647LA, ZE5701US, ZE5731US,
ZE5738RS, ZE5739CL, ZE7185
Acer Aspire: 1300, 1301XV, 1302, 1304, 1315LT
ECS: G550, G551, G710, G730, G731, G732, G736
IBM I series: 1400 Series, 1500 Series
Packard Bell Easynote: 7321, 7521
Fujitsu Siemens C Series LifeBook:
C1020, C2111
DC Power Jack, Part #PJ002
Available in center pin sizes 2.0 and 2.5mm
Gateway Solo: 2200, 2250, 2300, 2500, 2550, 5100
Compaq Presario 700US, 700xx, 700Z, 705US, 709EA, 710CA, 710TC, 710US, 711AU, 711CL, 711EA, 711LA, 712EA, 712LA, 713EA, 715CA, 715EA, 717RSH, 720AU, 720CA, 720JP, 720LA, 720TC, 721CL, 722EA, 722US, 723EA, 723RSH, 725AU, 725CA, 725EA, 725LA, 725US, 726EA, 730AP, 730US, 735CA
Compaq Presario* 1200SC, 1200T, 1200TH, 1200xx, 1200Z, 1201T, 1210, 1210US, 1211, 1212, 1214, 1215US, 1219JP
Compaq Presario 12XL, 12XL201, 12XL202, 12XL203, 12XL204, 12XL205, 12XL206, 12XL211, 12XL212, 12XL212, 12XL220, 12XL222, 12XL223, 12XL3, 12XL300, 12XL300A, 12XL300B, 12XL301, 12XL302, 12XL303, 12XL304, 12XL305, 12XL307, 12XL310, 12XL311, 12XL312, 12XL314, 12XL320, 12XL323, 12XL325, 12XL326, 12XL327, 12XL330, 12XL402, 12XL403, 12XL411, 12XL412, 12XL414, 12XL416, 12XL421, 12XL426, 12XL427, 12XL428, 12XL430, 12XL500, 12XL501, 12XL502, 12XL504, 12XL505, 12XL509, 12XL510, 12XL512, 12XL513, 12XL515, 12XL517, 12XL519, 12XL520, 12XL521, 12XL526, 12XL527, 12XL530, 12XL531
Compaq Presario 14XL, 14XL240, 14XL241, 14XL242, 14XL340, 14XL341, 14XL342, 14XL343, 14XL344, 14XL345, 14XL346, 14XL350, 14XL352, 14XL355, 14XL356, 14XL420, 14XL440, 14XL442, 14XL443, 14XL444, 14XL445, 14XL446, 14XL452, 14XL453, 14XL455
Compaq Presario* 1600, 1600T, 1650, 1655, 1600XL, 1600XL1, 16XL, 16XL140, 16XL141, 16XL142, 16XL143, 16XL144, 16XL145, 16XL146, 16XL147, 16XL150, 16XL255, 16XL256, 16XL257, 16XL258
Compaq Presario* 1700, 1700T, 1701S, 1702TC, 1710T, 1720CA, 1720US, 1722US
Compaq Presario 17XL, 17XL260, 17XL261, 17XL262, 17XL264, 17XL265, 17XL266, 17XL274, 17XL275, 17XL360, 17XL361, 17XL362, 17XL364, 17XL365, 17XL366, 17XL367, 17XL368, 17XL369, 17XL370, 17XL371, 17XL372, 17XL374, 17XL375, 17XL376, 17XL378, 17XL379, 17XL380, 17XL460, 17XL461, 17XL462, 17XL463, 17XL464, 17XL465, 17XL466, 17XL467, 17XL468, 17XL469, 17XL470, 17XL471, 17XL473, 17XL474, 17XL475, 17XL476, 17XL477, 17XL480, 17XL482, 17XL488, 17XL490, 17XL492, 17XL562, 17XL563, 17XL564, 17XL565, 17XL566, 17XL567, 17XL568, 17XL569, 17XL570, 17XL571, 17XL572, 17XL573, 17XL574, 17XL575, 17XL576, 17XL577, 17XL578, 17XL579, 17XL580
Compaq Presario* 1800, 1800T, 1805, 1825, 1827, 1830
Compaq Presario 18XL, 1800xx, 1800XL1, 18XL180, 18XL181, 18XL182, 18XL183, 18XL185, 18XL186, 18XL280, 18XL281, 18XL481, 18XL482, 18XL483, 18XL484, 18XL485, 18XL580, 18XL581, 18XL583, 18XL584, 18XL585, 18XL586, 18XL590
Compaq Armada 1100, 1120, 1120T, 1125, 1130, 1130T, 1135, 4110, 4115, 4110D, 4120, 4120T, 4125T, 4130T, 4131T, 4150, 4150T, 4160T, 4200, 4210, 4210T, 4220, 4220T
Compaq EVO Notebook N115,
N160
* Compaq is known to use several different types of
DC Jacks for these models, personal verification should be done prior to purchase.
HP Omnibook XE3 series
HP Pavilion N series N5000, N5125, N5135, N5140, N5150, N5170, N5190, N5195, N5210, N5221, N5240, N5241, N5250, N5261, N5270, N5271, N5290, N5295, N5310, N5311, N5331, N5340, N5341, N5350, N5351, N5361, N5371, N5381, N5390, N5401, N5430, N5440, N5441, N5444, N5450, N5451, N5461, N5470, N5474, N5481, N5490, N5491
Toshiba Satellite: 1605CDS, 1625CDT, 1675CDS, 1695CDT, 1715XCDS,
1730, 1730-S101, 1735-S101, 1750-S202, 1755-S202
Dell Inspiron: 3000, 3200, 3500, 7000
Dell Latitude: 433M, 433MC, 433MCX, 450MC, 450MCX, 475C, 475D, 475MC, LX4100, LX4100D, LX4100T
Dell Smart Step: 200, 250
Clevo: 220, TS30i, 2200T, 2700C
DC Power Jack, Part #PJ003
Available in center pin size 1.65, 2.0 and 2.5mm.
The optional Shield for this Jack is included in case you need it, if not simply remove it.
Acer Travelmate: C100, Z9000
Compaq Armada: M700
Compaq Presario M2000 series: M20xx, M21xx, M22xx, M23xx, M24xx, M25xx
HP Pavilion ZE2000 Series: ZE20xx, ZE21xx, ZE22xx, ZE23xx, ZE24xx, ZE25xx
Gateway Tablet: M1200, M1300
Gateway: M275, M305CRV, 400SD4, 400VTX, M405, 450SX4, 450ROG, 450RGH
Gateway Solo: 1150, 5300, 5350, 9100, 9150
HP Pavilion ZT series:
ZT1000, ZT1100, ZT1125, ZT1130, ZT1135, ZT1145, ZT1155, ZT1170, ZT1175, ZT1180, ZT1190, ZT1230, ZT1235, ZT1260
HP
Omnibook: XT1500
Toshiba Satellite: 1000, 1005, 1200, 3000-S303, 3000-S304, 3000-S307, 3000-S309, 3000-S353, 3000-S403, 3000-S514, 3005-S303, 3005-S303, 3005-S307, 3005-S308, 3005-S403, 3005-S504
IBM: I Series
Averatec: 2100, 2200, 3150, 3200, 3220, 3250, 3300, 5110H, 6200, 7100 Series
Clevo-Sager: 98
Asus: M3000N
Hyperdata: 3000
Versa: E120
DC Power Jack, Part #PJ004
Sony, most common of all
Sony PCG-FX: PCG-FX120, PCG-FX140, PCG-FX150, PCG-FX170, PCG-FX190, PCG-FX200, PCG-FX200K, PCG-FX210, PCG-FX215, PCG-FX220, PCG-FX240, PCG-FX250, PCG-FX270, PCG-FX290, PCG-FX310, PCG-FX318, PCG-FX340, PCG-FX370, PCG-FX390, PCG-FX410, PCG-FX677, PCG-FX776, PCG-FX777, PCG-FX876, PCG-FX877, PCG-FX430, PCG-FXA32, PCG-FXA33, PCG-FXA35, PCG-FXA36,
PCG-FXA47, PCG-FXA48, PCG-FXA49, PCG-FXA53, PCG-FXA59, PCG-FXA63
Sony PCG-GR: PCG-GR150, PCG-GR170, PCG-GR250, PCG-GR290, PCG-GR370, PCG-GR390, PCG-GRS150, PCG-GRS170, PCG-GRS175, PCG-GRS300, PCG-GRS700, PCG-GRS750, PCG-GRV550, PCG-GRV570, PCG-GRV670, PCG-GRV680, PCG-GRX500, PCG-GRX501, PCG-GRX510, PCG-GRX520, PCG-GRX530, PCG-GRX550, PCG-GRX560, PCG-GRX570, PCG-GRX580, PCG-GRX590, PCG-GRX606, PCG-GRX650, PCG-GRX670, PCG-GRX690, PCG-GRX700, PCG-GRX707, PCG-GRX770, PCG-GRZ530, PCG-GRZ600, PCG-GRZ610, PCG-GRZ630, PCG-GRZ660
Sony PCG-N: PCG-NVR5K, PCG-NVR7K, PCG-NVR17, PCG-NVR23, PCG-NVR27, PCG-NVR33, PCG-N505, PCG-N170, PCG-N190, PCG-N200, PCG-N290, PCG-NV105, PCG-NV109M, PCG-NV170, PCG-NV170P, PCG-NV190, PCG-NV290
Sony PCG-F: PCG-F150, PCG-F160, PCG-F180, PCG-F190, PCG-F250, PCG-F270, PCG-F280, PCG-F290, PCG-F340, PCG-F350, PCG-F360, PCG-F370, PCG-F390, PCG-F420, PCG-F430, PCG-F450, PCG-F480, PCG-F490, PCG-F505, PCG-F520, PCG-F540, PCG-F560, PCG-F570, PCG-F580, PCG-F590, PCG-F610, PCG-F630, PCG-F640, PCG-F650, PCG-F680, PCG-F690
Sony PCG-FR: PCG-FR130
Sony SR: PCG-SR5k, PCG-SR7k, PCG-SR17, PCG-SR27, PCG-SR33, PCG-SRX77, PCG-SRX87, PCG-SRX99
Sony TR: PCG-TR1, PCG-TR2
Sony VX: PCG-VX88, PCG-VX89
Sony XG: PCG-XG18, PCG-XG19, PCG-XG28, PCG-XG29, PCG-XG38, PCG-XG39, PCG-XG500, PCG-XG700
Panasonic Toughbook: CF01, CF17, CF25, CF27, CF28, CF33, CF34, CF35, CF37, CF45, CF47, CF48, CF61, CF62, CF63, CF71, CF72
Fujitsu Stylistic: LT P-600
Fujitsu Lifebook: I4187, 635T, B Series: B2545, B2562, B2566, B2545, B2562, B2566, C Series: C352, C320, C4235, C6527, C6581, C6631, C7651, P Series: P1120, P2120, S Series: S6000, S6210, S6231, T Series: T3010
DC Power Jack, Part #PJ005
Toshiba and Fujitsu, available in center pin size 2.5mm and 3.0mm
Fujitsu: C2010
Toshiba Libretto: 50 and 70 series
Toshiba Portege: 300, 310 and 320 series, 2000 series, 7000CT, 7010CT, 7020CT, 7140CT, 7200CT
Toshiba Satellite: 300CDS, 305CDS, 310CDs, 315CDS, 320CDS, 320CDT, 325CDS, 330CDS, 330CDT, 335CDS, 335CDT, 1200 SMALL BUSINESS, 1500, 1555, 1555CDS, 1800, 1800-S177, 1800-S202, 1800-S203, 1800-S204, 1800-S205, 1800-S206, 1800-S207, 1800-S253, 1800-S254, 1800-S256, 1800-S274, 1805, 1805-S154, 1805-S177, 1805-S203, 1805-S204, 1805-S207, 1805-S208, 1805-S253, 1805-S254, 1805-S255, 1805-S273, 1805-S274, 1805-S278, 2060, 2060CDS, 2060CDT, 2065, 2065CDS, 2065CDT, 2100, 2100CDS, 2100CDT, 2100CDX, 2105, 2105CDS, 2105CDT, 2115, 2115CDS, 2140, 2140CDT, 2140XCDS, 2180, 2180CDT, 2500, 2500CDS, 2500CDT, 2505, 2505CDS, 2505CDT, 2510, 2510CDS, 2510CDS/4, 2515, 2515CDS, 2515CDS/4, 2515CTS, 2520, 2520CDT, 2530, 2530CDS, 2530CDS/4, 2535, 2535CDS, 2535CDS/4, 2535CDT, 2540, 2540CDS, 2540CDS/4, 2540CDT, 2545, 2545CDS, 2545CDS/4, 2545CDT, 2545XCDT, 2545XCDT/4, 2590, 2590CDS, 2590CDS/4, 2590CDT, 2590XDVD, 2595, 2595CDS, 2595CDS/4, 2595CDT, 2595XDVD, 2600, 2610DVD, 2615, 2615DVD, 2655, 2655XDVD, 2675, 2675DVD, 2695, 2695DVD, 2700, 2710, 2710XDVD, 2715, 2715DVD, 2715XDVD, 2755, 2755DVD, 2755XDVD, 2770, 2770XDVD, 2775, 2775XDVD, 2800, 2800-S201, 2800-S202, 2800-S210, 2805, 2805-S201, 2805-S202, 2805-S301, 2805-S302, 2805-S401, 2805-S402, 2805-S503, 2805-S603, 2900 series, 4000, 4000CDS, 4000CDS/4, 4000CDT, 4000SCDS/4, 4005, 4005CDS, 4005CDS/4, 4005CDT, 4010, 4010CDS, 4010CDS/4, 4010CDT, 4015, 4015CDS, 4015CDS/4, 4015CDT, 4020, 4020CDT, 4020CDT/6, 4025, 4025CDS, 4025CDT, 4025CDT/6, 4030, 4030CDS, 4030CDT, 4030CDT/4, 4035, 4035CDT, 4060, 4060CDT, 4060CDT/4, 4060XCDT, 4070, 4070CDS, 4070CDT, 4080, 4080CDT, 4080XCDT, 4080XCDT/6, 4085, 4085XCDT, 4090, 4090CDS, 4090XCDT, 4090XDVD, 4090XDVD/6, 4100, 4100XCDT, 4100XDVD, 4100XDVD/6, 4260, 4260DVD, 4280, 4280XDVD, 4280ZDVD, 4300, 4300ZDVD, 4320, 4320ZDVD, 4340, 4340ZDVD, 4360, 4360ZDVD, 4600 Series, 5000, 5005, 5005-S504, 5005-S507, 5005-S508, 5005-S607, 5005-S608, 5100, 5105, 5105-S501, 5105-S502, 5105-S607, 5105-S608, 5105-S701, 5105-S702, 5105-S901, 5105-S902, 5200, 5205, 5205-S119, 5205-S502, 5205-S503, 5205-S504, 5205-S505, 5205-S506, 5205-S515, 5205-S703, 5205-S704, 5205-S705, 5205-S5151, 5205-SP505
Toshiba Satelite M30/M35 Board Harness: M30-S309, M30-S3091, M30-S350, M30-S3501, M30-SP309, M30-SP350, M35-S320, M35-S3201, M35-S359, M35-S3591, M35-S3592, M35-SP309, M35-SP350, M35-SP3501
Toshiba Satelite M20 Harness: M20, M20-S257, M20-S258
Pro: Pro 4280ZDVD, Pro 4280XDVD, Pro 4320, Pro 4340, Pro 4360, Pro 440CDT, Pro 440CDX, Pro 445CDX, Pro 460CDT, Pro 460CDX, Pro 465CDX, Pro 470CDT, Pro 480CDT, Pro 490CDT, Pro 490XCDT
Tecra: 500CDT, 500CS, 510CDT, 520CDT, 530CDT, 550CDT, 730XCDT, 750CDT, 750DVD, 780CDM, 780DVD, 8000 (12.1'' Active, Dual Scan, 13.3"' TFT), 8100 (13", 14" Display), 8200, 9000, 9100
Tecra Harness: PE2100, TE2000, TE2100, TE2300
DC Power Jack, Part #PJ006
Available center pin size 2.0mm and 2.5mm
Gateway: M500, M505
Toshiba Satellite: 1105, 1110-S153, 1115-S103, 1115-S104, 1115-S107, 1115-S123
HP Pavilion: N5415, N5425 and others from the N54xx series that use this type shield
IBM: R30, R31, R32
DC Power Jack, Part #PJ007, Available in center pin sizes 2.0mm and 2.5mm
Advent, Arm, Ashton Digital, Fujitsu, Hyperdata, Systemax, Uniwill
Advent, Arm, Ashton Digital, Hyperdata, Systemax, Uniwill:
N34AS1 & N351S1
Fujitsu: L6825, D1840, D1845, D7830
Note: Any of the models listed above may use either center pin sizes, please verify the size you need.
DC Power Jack, Part #PJ008
Toshiba and Gateway
Toshiba Satellite: A35, P35, A60, A65, M20 Series
Gateway: M675 (that uses the standard round ac adapter)
DC Power Jack, Part #PJ009
Toshiba
Toshiba Satellite: P10, P15, P20, P25 Series
DC Power Jack, Part #PJ010
HP and others please compare to Jack #11 & 15. This Jack stands 1.4mm higher at center pin, system board to center pin is 6.5mm.
DC Power Jack, Part #PJ011
Compaq, HP, IBM, Toshiba and Gateway. Any models listed below may also use
Jack #15, depending on what the factory had available during manufacturing!
HP ZD Series: ZD7000, ZD7001EA, ZD7001US, ZD7005EA, ZD7005QV, ZD7005US, ZD7009EA, ZD7010ca, ZD7010EA, ZD7010QV, ZD7010US, ZD7012EA, ZD7015EA, ZD7015US, ZD7020EA, ZD7020US, ZD7030EA, ZD7030US, ZD7035EA, ZD7038EA, ZD7040EA, ZD7040US, ZD7045EA, ZD7048CL, ZD7048EA, ZD7049EA, ZD7050, ZD7050EA, ZD7050US, ZD7055EA, ZD7058CL, ZD7060EA, ZD7063EA, ZD7065EA, ZD7066EA, ZD7070EA, ZD7080EA, ZD7101, ZD7101US, ZD7102US, ZD7112EA, ZD7120EA, ZD7128EA, ZD7129EA, ZD7131EA, ZD7139EA, ZD7140US, ZD7141, ZD7141EA, ZD7143EA, ZD7144EA, ZD7145EA, ZD7150EA, ZD7160ca, ZD7160US, ZD7167EA, ZD7168CL, ZD7168EA, ZD7169EA, ZD7170EA, ZD7180US, ZD7188CL, ZD7198CL, ZD7201US, ZD7202US, ZD7228EA, ZD7229EA, ZD7230EA, ZD7230US, ZD7235EA, ZD7236EA, ZD7245EA, ZD7248EA, ZD7249CL, ZD7250EA, ZD7255EA, ZD7256EA, ZD7257EA, ZD7258EA, ZD7259EA, ZD7260EA, ZD7260US, ZD7265EA, ZD7267EA, ZD7269CL, ZD7270EA, ZD7280US, ZD7283EA, ZD7300EA, ZD7310ca, ZD7310US, ZD7320EA, ZD7340EA, ZD7341EA, ZD7342EA, ZD7348EA, ZD7349EA, ZD7350EA, ZD7360US, ZD7373EA, ZD7374EA, ZD7375EA, ZD7376EA, ZD7377EA, ZD7378EA, ZD7379CL, ZD7379EA, ZD7380EA, ZD7380US, ZD7381EA, ZD7382EA, ZD7383EA, ZD7385EA, ZD7389CL, ZD7390EA, ZD7392EA, ZD7395EA, ZD7998US, ZD7999US
HP ZV series:
ZV5000, ZV5000t, ZV5000z, ZV5001US, ZV5002, ZV5002US, ZV5003AP, ZV5004AP, ZV5005AP, ZV5010AP, ZV5012AP, ZV5015AP, ZV5021AP, ZV5029AP, ZV5030US, ZV5034US, ZV5037WM, ZV5045EA, ZV5101US, ZV5103, ZV5103AP, ZV5103US, ZV5105US, ZV5120, ZV5120CA, ZV5120US, ZV5160, ZV5160CA, ZV5160US, ZV5200, ZV5200T, ZV5201, ZV5201US, ZV5202, ZV5210, ZV5210ca, ZV5210US, ZV5220, ZV5220US, ZV5240US, ZV5227, ZV5230, ZV5235, ZV5240, ZV5242QV, ZV5247LA, ZV5255US, ZV5257LA, ZV5260US, ZV5267LA, ZV5270US, ZV5277LA, ZV5287LA, ZV5316US, ZV5320, ZV5325, ZV5330, ZV5330, ZV5340, ZV5343, ZV5346, ZV5348, ZV5360, ZV5370, ZV5380, ZV5386, ZV6000
HP ZX series: ZX5000, ZX5002, ZX5040US, ZX5040EA, ZX5041, ZX5060US, ZX5065US, ZX5070US, ZX5078, ZX5180US, ZX5190US, ZX5200, ZX5275US, ZX5280US
HP Business NoteBook: NX9100 series, NX9110
Compaq Presario: R3000, R3000T, R3000Z, R3001, R3001US, R3002, R3003, R3003US, R3004, R3004US, R3005, R3005US, R3020, R3030, R3030US, R3038, R3038CL, R3040, R3050, R3050US, R3055, R3055CA, R3055US, R3056RS, R3060, R3060CA, R3060EA, R3060US, R3065, R3065US, R3070, R3070US, R3120CA, R3120US, R3140, R3140CA, R3140US, R3150, R3158, R3160, R3160US, R3190, R3190EA, R3190US, R3200, R3210, R3220, R3230, R3240, R3265, R3290, R3550US
Compaq Presario:
3000, 3000US, 3005, 3005US, 3008, 3008CL, 3015, 3015CA, 3015US, 3016US, 3017, 3017CL, 3017US, 3019, 3019CL, 3020, 3020US, 3045, 3045US, 3050, 3050US, 3070, 3070US, 3077, 3077WM, 3080, 3080US
*Gateway 4000 Series: M325, 4012GZ, 4024GZ, 4025GZ, 4026GZ, 4028GZ, 4028JP, 4030GZ, 4520GZ, 4525GZ, 4530GH, 4530GZ, 4535GZ, 4536GZ, 4538GZ, 4540GZ, 4541BZ, 4542GP, 4543BZ
*Gateway 7000 Series:
M520, 7110GX, 7210GX, 7215GX, 7305GZ, 7320GZ, 7322GZ,7324GZ, 7325GZ, 7326GZ, 7330GH, 7330GZ, 7405GH, 7405GX, 7410GX, 7415GX, 7422GX, 7426GX, 7508GX, 7510GX, MX7118, MX7315, MX7337, MX7337H, MX7340, MX7515, MX7515H, MX7525, S-7200C
IBM Thinkpad: 570E, 600, 600A, 600D, 600E, 600X, A20, A20M, A20P, A21, A21E, A21M, A21P, A22, A22E, A22M, A22P, A30, A30P, A31, A31P, X, X20, X21, X22, X23, X24, X30
Toshiba Satellite: A70, A75, A79, M30X, M35X, L15-S104, 1800, 1900, 1905, 1955
Acer TravelMate: 430, 1500, 1510, 2200
*eMachine: M2100 Series, M2300 series, M6800 Series
Fujitsu Amilo: L1300
Packard Bell: E5, E6
WinBook: 700 series
*Gateway is known to use both
2.0mm and 2.5mm center pin sizes, personal verification must be done in order to
get the correct part. The 2.5mm pin size is the most common size used, please see PJ012 for the 2.0mm size.
*eMachines is known to use both
1.65mm and 2.5mm center pin sizes, personal verification must be done in order to
get the correct part. The 2.5mm pin size is the most common size used, please see PJ013 for the 1.65mm size.
DC Power Jack, Part #PJ012
Gateway center pin 2.0mm
Gateway Solo: 9300 series
Gateway: M520 (note: The M520 is known to also use the 2.5mm center pin size, please verify what you need)
DC Power Jack, Part #PJ013
Compaq center pin 1.65mm
Compaq Presario: 900, 903, 904, 905, 906, 907, 908, 909, 910, 911, 912, 914, 915, 916, 917, 918, 919, 920, 921, 922, 925, 927, 930, 935, 940, 943, 945, 950, 955, 1500, 1505, 1507, 1508, 1510, 1515, 1522, 1523, 1525, 1527
Compaq EVO: N1000C, N1000V, N1005V, N1015V, N1020V
Note: This Jack is for use with AC adapter tips that are 5.5mm in diameter or larger only. Some systems only require 2 pins of the outer Shield, all you need to do is clip off or bend up the outer shield pins you do not need.
DC Power Jack, Part #PJ014
Compaq and Acer, center pin 1.65mm
Compaq Presario: X1000 CTO, X1001US, X1002US, X1005EA, X1005LA, X1006EA, X1007EA, X1010AL, X1010CA, X1010EA, X1010US, X1011AL, X1012AL, X1012EA, X1012QV, X1015US, X1016EA, X1018CL, X1020EA, X1020US, X1021AP, X1022AP, X1023AP, X1026AP, X1027AP, X1028AP, X1028CL, X1029AP, X1030AP, X1030US, X1031AP, X1032AP, X1033AP, X1034AP,
X1035AP, X1036AP, X1037AP, X1038AP, X1040AP, X1040US, X1041AP, X1042AP, X1043AP, X1044AP, X1045AP, X1046AP, X1047AP, X1048AP, X1049AP, X1050AP, X1050CA, X1050US, X1051AP, X1052AP, X1053AP, X1054AP, X1055AP, X1056AP, X1057AP, X1058AP, X1058CL, X1060AP, X1061AP, X1062AP, X1063AP, X1064AP, X1065AP, X1066AP, X1067AP, X1068AP, X1069AP, X1070AP, X1071AP, X1072AP, X1073AP, X1074AP, X1075AP, X1076AP, X1077AP, X1078AP, X1079AP, X1080AP, X1081AP, X1082AP, X1083AP, X1084AP, X1085AP, X1086AP, X1087AP, X1088AP, X1089AP, X1090AP, X1091AP, X1092AP, X1093AP, X1094AP, X1095AP, X1096AP, X1097AP, X1098AP, X1099AP, X1105EA, X1110EA, X1115EA, X1140EA, X1155EA, X1200, X1201AP, X1201US, X1202AP, X1203AP, X1204AP, X1205AP, X1206AP, X1207AP, X1208AP, X1209AP, X1210AP, X1210CA, X1210US, X1211AP, X1212AP, X1213AP, X1214AP, X1215AP, X1216AP, X1217AP, X1218AP, X1219AP, X1220AP, X1220EA, X1220US, X1221AP, X1222AP, X1223AP, X1224AP, X1225AP, X1227AP, X1228AP, X1229AP, X1230AP, X1230US, X1231AP, X1232AP, X1233AP, X1234AP, X1236AP, X1237AP, X1238AP, X1239AP, X1240AP, X1241AP, X1242AP, X1300 CTO, X1301AP, X1301US, X1302AP, X1303AP, X1304AP, X1305AP, X1306AP, X1307AP, X1308AP, X1309AP, X1310AP, X1311AP, X1312AP, X1313AP, X1314AP, X1315AP, X1316AP, X1317AP, X1318AP, X1319AP, X1320AP, X1321AP, X1322AP, X1324AP, X1325AP, X1326AP, X1327AP, X1328AP, X1329AP, X1330AP, X1360CA, X1360US, X1370US, X1390, X1390US, X1397, X1400 CTO, X1400AD, X1401AP, X1401US, X1402AP, X1402US, X1403AP, X1404AP, X1405AP, X1406AP, X1407AP, X1408AP, X1409AP, X1410AP, X1411AP, X1412AP, X1413AP, X1414AP, X1415AP, X1416AP, X1417AP, X1418AP, X1419AP, X1420AP, X1421AP, X1422AP, X1423AP, X1424AP, X1425AP, X1426AP, X1427AP, X1428AP, X1429AP, X1430AP, X1431AP, X1432AP, X1433AP, X1434AP, X1435AP, X1436AP, X1437AP, X1438AP, X1439AP, X1440AP, X1441AP, X1442AP, X1443AP, X1444AP, X1445AP, X1460CA, X1460US, X1480, X1480US, X1500 CTO, X1560CA
Business Notebook: NX7000
HP Pavilion: zt3xxx series, zt3001US, zt3001US, zt3007LA, zt3010AP, zt3010EA, zt3010US, zt3010US, zt3011AP, zt3012AP, zt3012EA, zt3013AP, zt3014AP, zt3015AP, zt3015EA, zt3016AP,
zt3017AP, zt3017EA, zt3017LA, zt3017WM, zt3017wm, zt3018AP, zt3019AP, zt3019EA, zt3020, zt3020AP, zt3020EA, zt3020US, zt3021AP, zt3022AP, zt3022EA, zt3023AP,
zt3024AP, zt3024EA, zt3025AP, zt3026AP, zt3027AP, zt3028AP, zt3029AP, zt3030AP, zt3030EA, zt3031AP, zt3032AP, zt3033AP, zt3034AP, zt3035AP, zt3036AP, zt3037AP, zt3038AP, zt3039AP, zt3040AP, zt3041AP, zt3042AP, zt3043AP, zt3044AP, zt3045AP, zt3046AP, zt3047AP, zt3048AP, zt3049AP, zt3050AP, zt3050EA, zt3051AP, zt3057LA, zt3068CL, zt3068cl, zt3100, series, zt3101EA, zt3101US, zt3101US, zt3105EA, zt3106EA, zt3110EA, zt3111EA, zt3113EA, zt3114EA, zt3115EA, zt3116EA, zt3120EA, zt3130EA, zt3131EA, zt3140US, zt3140us, zt3170US, zt3170us, zt3200, zt3201AP, zt3201us, zt3201us, zt3202AP, zt3203AP, zt3204AP, zt3205AP, zt3206AP, zt3207AP, zt3208AP, zt3209AP, zt3210AP, zt3210EA, zt3211AP, zt3211EA, zt3212AP, zt3212EA, zt3213AP, zt3214AP, zt3214EA, zt3215AP, zt3215EA, zt3216AP, zt3217AP, zt3218AP, zt3219AP, zt3220AP, zt3220EA, zt3221AP, zt3222AP, zt3223AP, zt3224AP, zt3225AP, zt3228AP, zt3229AP, zt3230AP, zt3231AP, zt3232AP, zt3232EA, zt3235AP, zt3236AP, zt3237AP, zt3239EA, zt3240EA, zt3241EA, zt3242EA, zt3250, zt3250us, zt3250us, zt3260EA, zt3280us, zt3280us, zt3300, zt3301AP, zt3301us, zt3302AP, zt3302us, zt3302us, zt3303AP, zt3304AP, zt3305AP, zt3306AP, zt3307AP, zt3308AP, zt3309AP, zt3310AP, zt3310EA, zt3311AP, zt3312AP, zt3312EA, zt3313AP, zt3314AP, zt3314EA, zt3315AP, zt3315EA, zt3316AP, zt3316EA, zt3317AP, zt3318AP, zt3319AP, zt3320AP, zt3320EA, zt3321AP, zt3322AP, zt3323AP, zt3324AP, zt3325AP, zt3326AP, zt3327AP, zt3328AP, zt3329AP, zt3329EA, zt3330AP, zt3330EA, zt3331AP, zt3332AP, zt3333AP, zt3334AP, zt3335AP, zt3336AP, zt3337AP, zt3338AP, zt3339AP, zt3340AP, zt3340EA, zt3340us, zt3340us, zt3341AP, zt3342AP, zt3343AP, zt3344AP, zt3345AP, zt3346AP, zt3347AP, zt3348AP, zt3349AP, zt3349cl, zt3349cl, zt3350AP, zt3350EA, zt3350us, zt3350us, zt3351AP, zt3351EA, zt3352AP, zt3353AP, zt3354AP, zt3355AP, zt3355us, zt3355us, zt3356AP, zt3357AP, zt3358AP, zt3359AP, zt3360AP, zt3368EA, zt3370EA, zt3377LA, zt3379LA, zt3380LA, zt3380us, zt3380us, zt3380XX,
zt3400 CTO, zt3418EA, zt3420EA, zt3440EA, zt3447EA, zt3449EA, zt3450EA, zt3451EA, zt3459EA, zt3460EA, zt3461EA, zt3462EA, zt3463EA, zt3464EA, zt3465EA
Acer TravelMate: C300, 622, 800, TM800, 800LCi, 800XC, 800XCi, 802, 802LCi, 803, 803LCi, 804, 804LMi, 2300 series, 2400 series, 4000 series,
5000 series
Acer Aspire: 1200 Series, 1410, 1500, 1520, 1610, 1620, 1641WLMI, 1642WLMI, 1660, 1670, 1680, 2001WLCi, 2303WLCI, 2413, 3000, 3002LCI, 3003WLCI, 3210, 3500, 3610, 4000 series, 4150, 4400, 5000 Series, 5003WLMi, 7100 Series, 8100 Series
DC Power Jack, Part #PJ015
Compaq, HP, Gateway, Toshiba and others. Any models listed below may also use
Jack #11, it all depended on what the factory had available during manufacturing
HP ZD Series: ZD7000, ZD7001EA, ZD7001US, ZD7005EA, ZD7005QV, ZD7005US, ZD7009EA, ZD7010ca, ZD7010EA, ZD7010QV, ZD7010US, ZD7012EA, ZD7015EA, ZD7015US, ZD7020EA, ZD7020US, ZD7030EA, ZD7030US, ZD7035EA, ZD7038EA, ZD7040EA, ZD7040US, ZD7045EA, ZD7048CL, ZD7048EA, ZD7049EA, ZD7050, ZD7050EA, ZD7050US, ZD7055EA, ZD7058CL, ZD7060EA, ZD7063EA, ZD7065EA, ZD7066EA, ZD7070EA, ZD7080EA, ZD7101, ZD7101US, ZD7102US, ZD7112EA, ZD7120EA, ZD7128EA, ZD7129EA, ZD7131EA, ZD7139EA, ZD7140US, ZD7141, ZD7141EA, ZD7143EA, ZD7144EA, ZD7145EA, ZD7150EA, ZD7160ca, ZD7160US, ZD7167EA, ZD7168CL, ZD7168EA, ZD7169EA, ZD7170EA, ZD7180US, ZD7188CL, ZD7198CL, ZD7201US, ZD7202US, ZD7228EA, ZD7229EA, ZD7230EA, ZD7230US, ZD7235EA, ZD7236EA, ZD7245EA, ZD7248EA, ZD7249CL, ZD7250EA, ZD7255EA, ZD7256EA, ZD7257EA, ZD7258EA, ZD7259EA, ZD7260EA, ZD7260US, ZD7265EA, ZD7267EA, ZD7269CL, ZD7270EA, ZD7280US, ZD7283EA, ZD7300EA, ZD7310ca, ZD7310US, ZD7320EA, ZD7340EA, ZD7341EA, ZD7342EA, ZD7348EA, ZD7349EA, ZD7350EA, ZD7360US, ZD7373EA, ZD7374EA, ZD7375EA, ZD7376EA, ZD7377EA, ZD7378EA, ZD7379CL, ZD7379EA, ZD7380EA, ZD7380US, ZD7381EA, ZD7382EA, ZD7383EA, ZD7385EA, ZD7389CL, ZD7390EA, ZD7392EA, ZD7395EA, ZD7998US, ZD7999US, ZD8000, ZD8002, ZD8003, ZD8004
HP ZV series: ZV5000, ZV5000t, ZV5000z, ZV5001US, ZV5002, ZV5002US, ZV5003AP, ZV5004AP, ZV5005AP, ZV5010AP, ZV5012AP, ZV5015AP, ZV5021AP, ZV5029AP, ZV5030US, ZV5034US, ZV5037WM, ZV5045EA, ZV5101US, ZV5103, ZV5103AP, ZV5103US, ZV5105US, ZV5120, ZV5120CA, ZV5120US, ZV5160, ZV5160CA, ZV5160US, ZV5200, ZV5200T, ZV5201, ZV5201US, ZV5202, ZV5210, ZV5210ca, ZV5210US, ZV5220, ZV5220US, ZV5240US, ZV5227, ZV5230, ZV5235, ZV5240, ZV5242QV, ZV5247LA, ZV5255US, ZV5257LA, ZV5260US, ZV5267LA, ZV5270US, ZV5277LA, ZV5287LA, ZV5316US, ZV5320, ZV5325, ZV5330, ZV5330, ZV5340, ZV5343, ZV5346, ZV5348, ZV5360, ZV5370, ZV5380, ZV5386, ZV6000
HP ZX series: ZX5000, ZX5002, ZX5040US, ZX5040EA, ZX5041, ZX5060US, ZX5065US, ZX5070US, ZX5078, ZX5180US, ZX5190US, ZX5200, ZX5275US, ZX5280US
Compaq Presario: R3000, R3000T, R3000Z, R3001, R3001US, R3002, R3003, R3003US, R3004, R3004US, R3005, R3005US, R3020, R3030, R3030US, R3038, R3038CL, R3040, R3050, R3050US, R3055, R3055CA, R3055US, R3056RS, R3060, R3060CA, R3060EA, R3060US, R3065, R3065US, R3070, R3070US, R3120CA, R3120US, R3140, R3140CA, R3140US, R3150, R3158, R3160, R3160US, R3190, R3190EA, R3190US, R3200, R3210, R3220, R3230, R3240, R3265, R3290, R3550US
Compaq Presario: 3000, 3000US, 3005, 3005US, 3008, 3008CL, 3015, 3015CA, 3015US, 3016US, 3017, 3017CL, 3017US, 3019, 3019CL, 3020, 3020US, 3045, 3045US, 3050, 3050US, 3070, 3070US, 3077, 3077WM, 3080, 3080US
IBM Thinkpad: 570E, 600, 600A, 600D, 600E, 600X, A20, A20M, A20P, A21, A21E, A21M, A21P, A22, A22E, A22M, A22P, A30, A30P, A31, A31P, X, X20, X21, X22, X23, X24, X30
Toshiba Satellite: A70, A75, A79, M30X, M35X, L15-S104, 1800, 1900, 1905, 1955
DC Power Jack, Part #PJ016
Acer, Asus, Dell, Packard Bell and Toshiba
Dell Inspiron: 1000, 1200, 1300, 2000, 2200, B120, B130
Toshiba Satellite: 1130 Series, 1135 Series, 2430 Series, 2435 Series
Acer Aspire: 1350
Acer Ferrari: 3000, 3000LMI, 3200, 3400, 4000
Acer
Travlemate: 2700, 4500
Asus: A2500H Series
Packard Bell Easynote: C3 Series, C3205, C3223, C3227, C3255, C3265, C3300, C3302
Chembook: CQ12-15
DC Power Jack, Part #PJ017
Compaq and HP
Compaq Presario V4000 Series: V4000
CTO, V4000, V4000T CTO, V4000XX, V4001AP, V4002AP, V4002XX, V4003AP, V4003XX, V4004AP, V4004XX, V4005CL, V4005XX, V4015US, V4020US, V4025US, V4035CA, V4035EA, V4035US, V4040EA, V4050EA, V4055EA, V4058EA, V4060EA, V4075EA, V4100
CTO, V4101AP, V4102AP, V4103AP, V4104AP, V4105AP, V4106AP, V4107AP, V4108AP, V4109AP, V4110AP, V4110EA, V4111AP, V4112AP, V4113AP, V4114AP, V4115AP, V4116AP, V4117AP, V4118AP, V4119AP, V4120EA, V4120TU, V4120US, V4121TU, V4122TU, V4125CL, V4130EA, V4133EA, V4135US, V4144EA, V4145EA, V4146EA, V4147EA, V4160EA, V4200
CTO, V4201TU, V4201XX, V4202EA, V4202TU, V4202XX, V4203EA, V4203TU, V4203XX, V4204TU, V4205EA, V4205TU, V4206TU, V4207TU, V4208TU, V4209TU, V4210TU, V4211TU, V4212TU, V4213TU, V4214TU, V4215EA, v4215TU, V4216TU, V4217EA, V4217TU, V4218TU, V4219TU, V4220EA, V4220NR, V4220TU, V4221TU, V4222TU, V4223TU, V4224TU, V4225TU, V4226TU, V4227TU, V4228TU, V4229TU, V4230TU, V4231TU, V4232TU, V4233TU, V4240US, V4245US, V4260EA, V4263EA, V4265EA, V4274EA, V4275EA, V4276EA, V4278EA, V4285EA, V4305EA, V4308EA, V4310NR, V4320EA, V4322EA, V4325CA, V4325US, V4332EA, V4332US, V4333EA, V4335EA, V4336EA, V4338EA, V4347EA, V4354EA, V4376EA, V4377EA, V4382EA, V4387EA, V4400
CTO, V4401TU, V4402TU, V4402XX, V4403TU, V4404TU, V4405TU, V4406TU, V4407TU, V4408TU, V4435NR, V4440US, V4450EA
HP Pavilion DV4000 Series: DV4000
CTO, DV4000LA, DV4000XX, DV4001AP, DV4001EA, DV4001XX, DV4002AP, DV4003AP, DV4004AP, DV4004XX, DV4005AP, DV4005US, DV4005XX, DV4006AP, DV4006XX, DV4007AP, DV4007XX, DV4008AP, DV4009AP, DV4010AP, DV4011AP, DV4012AP, DV4013AP, DV4014AP, DV4014EA, DV4015AP, DV4015CL, DV4015EA, DV4016AP, DV4016EA, DV4017AP, DV4017EA, DV4018AP, DV4018CL, DV4018EA, DV4019AP, DV4019EA, DV4020AP, DV4020EA, DV4021AP, DV4021EA, DV4022AP, DV4022EA, DV4023AP, DV4023EA, DV4024AP, DV4024EA, DV4025AP, DV4025EA, DV4026AP, DV4027EA, DV4029EA, DV4030CA, DV4030EA, DV4030US, DV4031EA, DV4040CA, DV4040EA, DV4040US, DV4043EA, DV4045EA, DV4046EA, DV4049EA, DV4050EA, DV4051EA, DV4052EA, DV4054EA, DV4056EA, DV4057EA, DV4060EA, DV4070EA, DV4073EA, DV4075EA, DV4078EA, DV4080EA, DV4085EA, DV4086EA, DV4100
CTO, DV4100, DV4101AP, DV4102AP, DV4102EA, DV4103AP, DV4103EA, DV4104AP, DV4105AP, DV4106AP, DV4107AP, DV4108AP, DV4108EA, DV4109AP, DV4109EA, DV4110AP, DV4110EA, DV4111AP, DV4112AP, DV4113AP, DV4113EA, DV4114AP, DV4115AP, DV4115EA, DV4116AP, DV4117AP, DV4118AP, DV4119AP, DV4120AP, DV4121AP, DV4122AP, DV4122EA, DV4123AP, DV4124AP, DV4124EA, DV4125AP, DV4125EA, DV4125US, DV4126AP, DV4126EA, DV4127AP, DV4128AP, DV4128EA, DV4129AP, DV4129EA, DV4129US, DV4130AP, DV4130ea, DV4130US, DV4131EA, DV4134EA, DV4135EA, DV4135LA, DV4136EA, DV4137EA, DV4138EA, DV4139EA, DV4140EA, DV4141EA, DV4142EA, DV4143EA, DV4144EA, DV4145EA, DV4146EA, DV4148EA, DV4149EA, DV4150CA, DV4150EA, DV4150US, DV4151EA, DV4152EA, DV4153EA, DV4154EA, DV4155CL, DV4155EA, DV4155US, DV4156EA, DV4157EA, DV4158EA, DV4159EA, DV4160EA, DV4161EA, DV4162EA, DV4163EA, DV4164EA, DV4165CL, DV4165EA, DV4170CA, DV4170US, DV4174EA, DV4176EA, DV4178EA, DV4182EA, DV4199EA, DV4200
CTO, DV4200, DV4200EA, DV4201EA, DV4201TU, DV4201TX, DV4201XX, DV4202EA, DV4202TU, DV4202TX, DV4202XX, DV4203EA, DV4203TU, DV4203TX, DV4203XX, DV4204EA, DV4204TU, DV4204TX, DV4205EA, DV4205TU, DV4205TX, DV4206EA, DV4206TU, DV4206TX, DV4207EA, DV4207TU, DV4207TX, DV4208EA, DV4208TX, DV4209TX, DV4210TX, DV4211TX, DV4212TX, DV4213EA, DV4213TX, DV4214TX, DV4215TX, DV4216EA, DV4216TX, DV4217CL, DV4217TX, DV4218EA, DV4218TX, DV4219TX, DV4220TX, DV4221TX, DV4222TX, DV4223CL, DV4223EA, DV4223TX, DV4224EA, DV4224TX, DV4225EA, DV4225NR, DV4225TX, DV4226EA, DV4226TX, DV4227EA, DV4230US, DV4231EA, DV4232EA, DV4234EA, DV4235EA, DV4236EA, DV4241EA, DV4243EA, DV4245EA, DV4246EA, DV4250CA, DV4250EA, DV4250US, DV4251EA, DV4253EA, DV4253US, DV4254EA, DV4257US, DV4261EA, DV4264EA, DV4266EA, DV4268EA, DV4269EA, DV4269US, DV4270CA, DV4270EA, DV4270US, DV4271EA, DV4272EA, DV4272US, DV4273EA, DV4275EA, DV4275NR, DV4276EA, DV4277EA, DV4280EA, DV4282EA, DV4283EA, DV4284EA, DV4285EA, DV4287EA, DV4288EA, DV4289EA, DV4290EA, DV4291EA, DV4294EA, DV4295EA, DV4296EA, DV4302EA, DV4304EA, DV4305EA, DV4305US, DV4306EA, DV4307CA, DV4307CL, DV4308WM, DV4309EA, DV4310US, DV4312EA, DV4315EA, DV4318EA, DV4320US, DV4321EA, DV4322EA, DV4324EA, DV4325EA, DV4326EA, DV4327EA, DV4330CA, DV4330US, DV4334EA, DV4335EA, DV4335NR, DV4336EA, DV4337EA, DV4339EA, DV4340CA, DV4340US, DV4342EA, DV4344EA, DV4346EA, DV4348EA, DV4350EA, DV4351EA, DV4353EA, DV4354EA, DV4356EA, DV4357EA, DV4358EA, DV4360EA, DV4363EA, DV4364EA, DV4365EA, DV4367EA, DV4368EA, DV4376EA, DV4378EA, DV4379EA, DV4381EA, DV4383EA, DV4384EA, DV4385EA, DV4386EA, DV4388EA, DV4391EA, DV4392EA, DV4394EA, DV4395EA, DV4396EA, DV4398EA, DV4400
CTO, DV4401TU, DV4401XX, DV4402TU, DV4405NR, DV4410CA, DV4410US, DV4419US, DV4420CA, DV4420US, DV4430EA, DV4435EA, DV4440EA, DV4445EA, DV4450EA
DC Power Jack, Part #PJ018
Gateway M, NX, S, 3000 and 6000 series
Gateway: M210, M250GS, M250G, M250ES, M250E, M250A, M250B, M360, M360A, M360B, M360C, M460, M460A, M460B, M465QS, M465G, M465E,
M520, NX100X, NX200S, NX200X, NX250X, NX500S, NX500S w/S-Video, NX500X, NX500X w/S-Video, NX510S, NX550X, NX550XL, NX560X, NX560XL, S-7200N, S-7500N, S-7510N, S-7700N, S-7710N
Gateway 3000 Series: 3018GZ, 3040GZ, 3520GZ, 3522GZ, 3525GB, 3545GZ, 3550GH, 3550GZ, 3610GZ, MX3042, MX3044, MX3044h, MX3210, MX3212, MX3215, MX3225, MX3228, MX3228h, MX3230, MX3231, MX3311b, MX3410,
MX3410h, MX3412, MX3412h, MX3414, MX3416, MX3417, MX3422, MX3558, MX3558h, MX3560, MX3560h, MX3562, MX3563, MX3563h, MX3610, MX3701, MX3702
Gateway 6000 Series:
6010GZ, 6018GH, 6018GZ, 6020GZ, 6021GZ, 6022GZ, 6023GP, 6510GZ, 6518GZ, 6520GZ, 6525GP, 6531GZ, MX6025, MX6025h, MX6027, MX6027h, MX6028, MX6030, MX6121, MX6123, MX6124, MX6124h, MX6128, MX6131, MX6135, MX6214, MX6216, MX6420, MX6421, MX6422, MX6423, MX6424, MX6424h, MX6425, MX6426, MX6427, MX6428, MX6429, MX6430, MX6431, MX6433, MX6436, MX6437, MX6438, MX6439, MX6440, MX6440h, MX6441, MX6442, MX6444, MX6444h, MX6445, MX6446, MX6447, MX6448, MX6450, MX6452, MX6453, MX6454, MX6455, MX6625, MX6627, MX6627h, MX6629, MX6629h, MX6631, MX6633, MX6633h, MX6640b, MX6641 MX6641h, MX6650, MX6650h, MX6708, MX6708h, MX6710, MX6750, MX6750h, MX6912, MX6919, MX6920, MX6920h, MX6927, MX6930, MX6930h, MX6931, MX6951, MX6951h, MX6955, MX6956, MX6957, MX6958, MX6959, MX6960, MX6961, MX6961h
DC Power Jack, Part #PJ019
Compaq and HP
Compaq Presario V2000 series: V20xx, V21xx, V22xx, V23xx, V24xx, V25xx, V26xx
HP Pavilion DV1000 Series: DV10xx, DV11xx, DV12xx, DV13xx, DV14xx, DV15xx, DV16xx, DV17xx
HP Compaq Business Notebook: NX4800, NX4820
The listings below are for the Jacks for the Main System Board only, not the Power Connector Board. Please see PJ003-1.65mm here for the Power Connector Board Jack that the AC adapter plugs into.
Compaq Presario M2000 series: M20xx, M21xx, M22xx, M23xx, M24xx, M25xx
HP Pavilion ZE2000 Series: ZE20xx, ZE21xx, ZE22xx, ZE23xx, ZE24xx, ZE25xx
DC Power Jack, Part #PJ020
HP-Compaq
HP-Compaq: NX6110, NC6110, NX6120, NC6120, NX8200 Series, NC8200 Series
DC Power Jack, Part #PJ021
Gateway
Gateway: M350 and M675 that uses the DIN style AC adapter plug.
DC Power Jack, Part #PJ022
Gateway, Micron and Samsung
Gateway: 200ARC
Samsung: X10, V20, V25, VM6000, VM7000
Micron: Metrobook VL Plus and Transport GX series
DC Power Jack, Part #PJ023
Samsung
Samsung: A10
DC Power Jack, Part #PJ024
Samsung
Samsung: P10, Taurus
VPR-Matrix: 120-180b5
DC Power Jack, Part #PJ025
Samsung
Samsung: V25, V30
DC Power Jack, Part #PJ026
Gateway and Samsung
Gateway: 200STM
Samsung: Q series
DC Power Jack, Part #PJ027
HP
Compaq Presario V5000 Series: V5000 CTO, V5000T CTO, V5002EA, V5004EA, V5005US, V5006EA, V5009EA, V5015CA, V5015US, V5025EA, V5026EA, V5030EA, V5031EA, V5032EA, V5033EA, V5054EA, V5059EA, V5079EA, V5088XX, V5094EA, V5099EA, V5099XX, V5100 CTO, V5100AU, V5100TU, V5101AU, V5101TU, V5101US, V5102AU, V5102EU, V5102NR, V5102TU, V5103AU, V5103TU, V5104AU, V5104EU, V5104TU, V5105CA, V5105EU, V5105TU, V5105US, V5106EU, V5106TU, V5107EU, V5107TU, V5108CU, V5108EU, V5108TU, V5109TU, V5110EU, V5110TU, V5111EU, V5111TU, V5115CA, V5115EU, V5115US, V5116EU, V5119US, V5120EU, V5120NR, V5122EU, V5125EU, V5126EU, V5128EA, V5132EA, V5150EA, V5155EA, V5160EA, V5160US, V5162EA, V5189XX, V5199XX, V5200 CTO, V5201CA, V5201TU, V5201US, V5202TU, V5203TU, V5204NR, V5204TU, V5204US, V5205NR, V5205TU, V5206OM, V5206TU, V5207NR, V5207TU, V5208CA, V5208TU, V5209TU, V5209US, V5210CA, V5210TU, V5210US, V5211TU, V5212TU, V5213TU, V5214EA, V5214TU, V5215EA, V5215LA, V5215TU, V5216EA, V5216TU, V5217TU, V5218LA, V5218TU, V5219TU, V5220EA, V5220TU, V5221EA, V5221TU, V5222EA, V5222TU, V5223TU, V5224TU, V5225TU, V5226TU, V5227TU, V5228TU, V5229TU, V5230TU, V5231TU, V5232EA, V5232TU, V5233EA, V5233TU, V5234EA, V5234TU, V5235EA, V5235TU, V5236EA, V5236EU, V5236TU, V5237TU, V5238TU, V5239TU, V5240TU, V5241TU, V5242TU, V5243TU, V5244TU, V5245EU, V5245TU, V5246TU, V5247TU, V5248TU, V5249TU, V5250TU, V5251TU, V5252TU, V5253TU, V5254TU, V5255TU, V5256TU, V5257TU, V5258TU, V5259TU, V5260TU, V5261TU, V5299XX, V5300 CTO, V5303NR, V5304US, V5305WM, V5306US, V5307US, V5308CA, V5310US, V5315WM
Compaq Presario C300 Series: C300 CTO, C300EA, C300EU, C301NR, C301TU, C302NR, C302TU, C303NR, C303TU, C304NR, C304TU, C305LA, C305TU, C306TU, C306US, C307NR, C307TU, C308LA, C308TU, C309TU, C310EA, C310EU, C310TU, C311TU, C312TU, C313TU, C315LA, C318LA, C350EA, C350EU, C351EA, C352EA, C353EA, C399XX
Compaq Presario C500 Series: C500, C500EA, C500EU, C500T, C501NR, C501TU, C502CA, C502EA, C502EU, C502TU, C502US, C503TU, C503WM, C504EA, C504EU, C504TU, C504US, C505TU, C506CA, C506TU, C507TU, C507US, C508US, C509NR, C518LA, C540EA, C542EA, C550ED, C550EF, C550EL, C550EM, C551NR, C551TU, C552CA, C552TU, C552US, C553TU, C554EM, C554TU, C554US, C555EA, C555EL, C555EM, C555ES, C555EU, C555NR, C555TU, C556CA, C556EM, C556TU, C557CL, C557TU, C558TU, C559CL, C559EF, C559EM, C559TU, C560TU, C560US, C561TU, C562TU, C563NR, C563TU, C564TU, C564US, C565TU, C566TU, C567TU, C568LA, C570EA, C571NR, C571TU, C572TU, C573TU, C574TU, C575TU, C576TU, C577TU, C578TU, C579TU, C580TU, C581TU, C581WM, C582TU
HP Pavilion DV5000 Series: DV5000 CTO, DV5000ea, DV5000t CTO, DV5001xx, DV5002ea, DV5003cl, DV5003ea, DV5005ea, DV5006ea, DV5007ea, DV5008ea, DV5009ea, DV5010ea, DV5011ea, DV5012ea, DV5016ea, DV5017cl, DV5017ea, DV5018ea, DV5020ca, DV5020us, DV5021ea, DV5022ea, DV5023ea, DV5024ea, DV5026ea, DV5027ea, DV5029us, DV5030us, DV5031ea, DV5033ea, DV5034ea, DV5035ea, DV5035nr, DV5036ea, DV5037ea, DV5040us, DV5041ea, DV5046ea, DV5047ea, DV5050ea, DV5051ea, DV5052ea, DV5053ea, DV5054ea, DV5055ea, DV5056ea, DV5057ea, DV5058ea, DV5059ea, DV5061ea, DV5062ea, DV5063ea, DV5074ea, DV5075ea, DV5077ea, DV5078ea, DV5084ea, DV5088xx, DV5091ea, DV5092ea, DV5093ea, DV5094ea, DV5095ea, DV5096ea, DV5097ea, DV5098ea, DV5099ea, DV5099xx
Pavilion DV8000 Series: DV8000 CTO, DV8000T CTO, DV8002EA, DV8005EA, DV8010EA, DV8013CL, DV8013xx, DV8025EA, DV8026EA, DV8027EA, DV8028EA, DV8029EA, DV8030EA, DV8035EA, DV8040CA, DV8040US, DV8040xx, DV8045EA, DV8050EA, DV8051EA, DV8075EA, DV8088US, DV8099xx
Note: This is the Jack only and does not include the harness. You will need to reuse your harness.
DC Power Jack, Part #PJ028
Acer
Acer: TM370, C110
DC Power Jack, Part #PJ029
HP OmniBook
HP OmniBook: OmniBook 900
DC Power Jack, Part #PJ030
Dell
Dell Inspiron: 500M, 600M, 700M, E1505, 1150, 5150, 5160, 6000, 8500, 8600, 9100, 9200, 9300, 9400
Dell Latitude:
100L, D400, D410, D500, D505, D510, D520, D600, D610, D800, D810
Dell Precision Workstation:
M20, M60
DC Power Jack, Part #PJ031
Dell
Dell Latitude: C-Series, CP,
CPi, CPiA, CPiD, CPiR, CPm, CPt, CPtC, CPtS, CPtV, CPx, CPxH, CPxJ, CS, CSR, CSX, C400, C500, C510, C540, C600, C610, C640, C800, C805, C810, C840, C-Dock, C-Port, V700, V710, V740, Xpi 133ST, Xpi 75, Xpi CD, Xpi P100SD, XPi P133
Dell Inspiron:
1100, 2500, 2600, 2650, 3650, 3700, 3800, 4000, 4100, 4150, 5000, 5000E, 5100, 7500, 8000, 8100, 8200
Dell Precision Workstation:
M40, M50
DC Power Jack, Part #PJ032
HP/Compaq
HP/Compaq Business Notebook: NX5000 series
Compaq Presario V1000 series:
V1000 CTO, V1001AD, V1001AP, V1002AD, V1002AP, V1003AD, V1003AP, V1004, V1004AD, V1004AP, V1005AD, V1005AP, V1006AD, V1006AP, V1007AD, V1007AP, V1008AD, V1008AP, V1009AD, V1009AP, V1010AP, V1011AP, V1012AP, V1013AP, V1014AP, V1015AP, V1016AP, V1017AP, V1018AP, V1019AP, V1020AP, V1021AP, V1022AP, V1023AP, V1024AP, V1025AP, V1026AP, V1027AP, V1028AP, V1029AP, V1030AP, V1031AP, V1032AP, V1033AP, V1034AP, V1035AP, V1036AP, V1037AP, V1038AP, V1039AP, V1040AP, V1041AP, V1042AP, V1043xx, V1044AP, V1045AP, V1046AP, V1047AP, V1048AP, V1049AP, V1050AP, V1051AP, V1052AP, V1053AP, V1054AP, V1055AP, V1056AP, V1057AP, V1058AP, V1059AP, V1060AP, V1061AP, V1062AP, V1065AP, V1066AP, V1067AP, V1068AP, V1069AP, V1070AP, V1071AP, V1072AP, V1073AP, V1074AP, V1075AP, V1100 CTO, V1101AP, V1102AP, V1103AP, V1104AP, V1105AP, V1106AP, V1107AP, V1108AP, V1109AP, V1110AP, V1111AP, V1112AP, V1113AP, V1114AP, V1115AP, V1116AP, V1117AP, V1118AP, V1119AP, V1120AP, V1121AP, V1122AP, V1123AP, V1124AP, V1125AP, V1126AP, V1127AP, V1128AP, V1129AP, V1130AP, V1131AP, V1132AP, V1133AP, V1134AP
DC Power Jack, Part #PJ033
Fujitsu Siemens
Fujitsu Amilo: M1405, M7405, Pro V2040
DC Power Jack, Part #PJ034
Acer
Acer: Compatible models coming soon.
DC Power Jack, Part #PJ035
HP, Compaq
HP ZV6000 Series: zv6000 CTO, zv6000, zv6001XX, zv6002XX, zv6003XX, zv6004EA, zv6004XX, zv6005US, zv6006EA, zv6007US, zv6008CL, zv6009EA, zv6009US, zv6010EA,
zv6010US, zv6011EA, zv6013EA, zv6015US, zv6017EA, zv6020EA, zv6024EA, zv6025EA, zv6026EA, zv6027EA, zv6028EA, zv6029EA, zv6061EA, zv6062EA, zv6064EA,
zv6065EA, zv6066EA, zv6067EA, zv6068EA, zv6069EA, zv6090EA, zv6100 CTO, zv6100, zv6107WM, zv6114EA, zv6115EA, zv6116EA, zv6117EA, zv6118EA, zv6120EA,
zv6123CL, zv6125CL, zv6126EA, zv6127EA, zv6128EA, zv6129EA, zv6130EA, zv6130US, zv6131EA, zv6131US, zv6147EA, zv6148EA, zv6149EA, zv6150EA, zv6151EA,
zv6152EA, zv6153EA, zv6156EA, zv6158EA, zv6159EA, zv6170CA, zv6170US, zv6174EA, zv6179EA, zv6180EA, zv6181EA, zv6195EA, zv6196EA, zv6201CL, zv6201EA,
zv6203CL, zv6209US, zv6211EA, zv6212EA, zv6213EA, zv6214EA, zv6215EA, zv6216EA, zv6217EA, zv6218EA, zv6220EA, zv6223CL, zv6230CA, zv6233NR, zv6242EA,
zv6243EA, zv6244EA, zv6245EA, zv6246EA, zv6247EA, zv6248EA, zv6249EA, zv6250EA, zv6251EA, zv6252EA, zv6253EA, zv6254EA, zv6255EA, zv6270CA, zv6270US,
zv6273EA, zv6274EA, zv6275EA, zv6276EA, zv6278EA, zv6279EA, zv6295EA, zv6296EA, zv6302US
HP ZD8000 Series:
zd8000 CTO, zd8001AP, zd8001XX, zd8002AP, zd8002XX, zd8003AP, zd8003XX, zd8004AP, zd8004XX, zd8005AP, zd8007EA, zd8008EA, zd8009EA, zd8010EA, zd8010XX,
zd8011XX, zd8015EA, zd8017EA, zd8019EA, zd8020EA, zd8030EA, zd8043EA, zd8044EA, zd8045EA, zd8047EA, zd8048EA, zd8050EA, zd8050LA, zd8050XX, zd8051EA,
zd8052EA, zd8053EA, zd8054EA, zd8055US, zd8060CA, zd8060US, zd8070EA, zd8072EA, zd8075EA, zd8076EA, zd8077EA, zd8078EA, zd8079EA, zd8080EA, zd8080us,
zd8100 CTO, zd8105CA, zd8105EA, zd8110EA, zd8110US, zd8112EA, zd8115EA, zd8115US, zd8120CL, zd8120EA, zd8122EA, zd8123EA, zd8124EA, zd8125CL, zd8125EA,
zd8126EA, zd8127EA, zd8129EA, zd8130EA, zd8135EA, zd8139EA, zd8147EA, zd8148EA, zd8150EA, zd8151EA, zd8155EA, zd8156EA, zd8157EA, zd8158EA, zd8159EA,
zd8160EA, zd8162EA, zd8179EA, zd8180EA, zd8181EA, zd8182EA, zd8183EA, zd8184EA, zd8185EA, zd82xxus, zd8200 CTO, zd8201AP, zd8202AP, zd8203AP, zd8204AP,
zd8205TU, zd8205US, zd8210CA, zd8214EA, zd8215US, zd8217EA, zd8218EA, zd8219EA, zd8220us, zd8223EA, zd8224EA, zd8225CA, zd8225EA, zd8226EA, zd8227EA,
zd8228EA, zd8229EA, zd8230EA, zd8230us, zd8231EA, zd8234EA, zd8235EA, zd8237EA, zd8238EA, zd8239EA, zd8245EA, zd8250LA, zd8251EA, zd8252EA, zd8253EA,
zd8254EA, zd8255EA, zd8256EA, zd8270EA, zd8280EA, zd8289EA, zd8290EA, zd8291EA, zd8301EA, zd8302EA, zd8303EA, zd8304EA, zd8305EA, zd8306EA, zd8307EA,
zd8308EA, zd8315CA, zd8315EA, zd8316EA, zd8317EA, zd8318EA, zd8319EA, zd8320EA, zd8323EA, zd8325EA, zd8333CL, zd8342EA, zd8350LA, zd8367EA, zd8368EA,
zd8369EA, zd8388EA, zd8389EA, zd8390EA, zd8398EA, zd8399EA, zd8399xx, zd8401EA, zd8410EA, zd8430CA, zd8460EA, zd8480EA, zd8490EA
HP/Compaq Business Notebook:
NX9600 Series
Compaq Presario X6000 Series: X6000 CTO, X6001XX, X6002XX, X6003XX, X6050CA, X6050US, X6070US, X6100 CTO, X6105CL, X6110US, X6125CL
Compaq Presario R4000 Series:
R4000 CTO, R4000, R4001XX, R4002XX, R4003EA, R4003XX, R4005EA, R4006EA, R4009EA, R4010CA, R4010US, R4012EA, R4012US, R4015EA, R4016EA, R4017EA, R4024EA,
R4025CA, R4025EA, R4025US, R4026EA, R4028EA, R4029EA, R4030EA, R4031EA, R4035CA, R4060EA, R4065EA, R4075EA, R4207EA, R4221EA, R4100 CTO, R4114EA, R4115EA,
R4115US, R4125CA, R4125EA, R4125US, R4126EA, R4127EA, R4127US, R4130EA, R4145EA, R4146EA, R4150EA, R4155EA, R4157EA, R4205EA, R4206EA, R4208EA, R4209EA,
R4218EA, R4219EA, R4220EA, R4222EA, R4225CA
DC Power Jack, Part #PJ036
Sony
Sony VGN: VGN-FS620 (PCG-7A2L), VGN-FS620P, VGN-FS625B, VGN-FS635B, VGN-FS640, VGN-FS640W, VGN-FS645P, VGN-FS660, VGN-FS660P, VGN-FS675P, VGN-FS680
Sony Z505: PCG-Z505ES, PCG-Z505ESK, PCG-Z505FA, PCG-Z505FAT, PCG-Z505GA, PCG-Z505GAT, PCG-Z505GE, PCG-Z505HE, PCG-Z505HS, PCG-Z505HSK, PCG-Z505LE, PCG-Z505LEK, PCG-Z505LS (PCG-531A), PCG-Z505JEK, PCG-Z505JSK, PCG-Z505JE (PCG-5211), PCG-Z505JS (PCG-5201), PCG-Z505LE, PCG-Z505LEK, PCG-Z505R, PCG-Z505RX, PCG-Z505S, PCG-Z505SX
DC Power Jack, Part #PJ037
Gateway
Gateway Solo: 3400, 3450
DC Power Jack, Part #PJ038
Acer
Acer TravelMate: 290e, 2350, 4200
Acer Aspire: 3100, 3690, 4720Z, 5070, 5100, 5610Z, 9500
DC Power Jack, Part #PJ039
Roadmate GPS System
Roadmate GPS System: 300
DC Power Jack, Part #PJ040
Sony
Sony PCG-K Series: PCG-K12, PCG-K12P, PCG-K13, PCG-K13F, PCG-K14, PCG-K15, PCG-K15F (PCG-9P6L), PCG-K17, PCG-9P6L, PCG-K23, PCG-K25, PCG-K27, VGN-K31, VGN-K31B, PCG-K33, PCG-K33P, PCG-K33F, PCG-K33Q, PCG-K34FP, PCG-K35, PCG-K35F, PCG-K37 (PCG-9S1L), PCG-K45, PCG-K43F, PCG-K43Q, PCG-K44FP, PCG-K45F, PCG-K47, PCG-K64, PCG-K66P, VGN-K71B, PCG-K86P, PCG-K86SP, PCG-K315B, PCG-K315M, PCG-K315S, PCG-K315Z, PCG-K415B, PCG-K415S
Sony VGN-A Series: VGN-A21, VGN-A51PS1, VGN-A51PS2, VGN-A51S1, VGN-A51S2, VGN-A61B, VGN-A71PS, VGN-A71S, VGN-A100, VGN-A130 (PCG-8Q8L), VGN-A130B, VGN-A130P (PCG-8Q9L), VGN-A140, VGN-A140P, VGN-A150, VGN-A160, VGN-A170 (PCG-8Q1L), VGN-A170B, VGN-A170P (PCG-8Q4L), VGN-A190 (PCG-8Q5L), VGN-A215M, VGN-A215Z, VGN-A217M, VGN-A230, VGN-A230B, VGN-A230P (PCG-8R9L), VGN-A240, VGN-A240B, VGN-A240P, VGN-A250, VGN-A260 (PCG-8R7L), VGN-A270, VGN-A270B, VGN-A270P (PCG-8R1L), VGN-A290, VGN-A290F (PCG-8R4L), VGN-A295HP, VGN-A297XP, VGN-A600, VGN-A600B, VGN-A600P (PCG-8S3L), VGN-A690 (PCG-8S4L), VGN-A790 (PCG-8T2L)
Sony VGN-AR Series: VGN-AR170 (PCG-8V1L)
Sony PCG-GRT Series: PCG-GRT100 (PCG-8M2R), PCG-GRT100K, PCG-GRT100P (PCG-8M1R), PCG-GRT150 (PCG-8M3L), PCG-GRT160 (PCG-8M4L), PCG-GRT170 (PCG-8M2L), PCG-GRT230 (PCG-8N2L), PCG-GRT240, PCG-GRT250, PCG-GRT250K, PCG-GRT260, PCG-GRT270, PCG-GRT270G, PCG-GRT270K, PCG-GRT270P (PCG-8N1L), PCG-GRT280ZG (PCG-8N3L), PCG-GRT350, PCG-GRT390
Sony VGN-BX Series: VGN-BX540B
Note: This is for the DC Jack only, you will need to reuse your exiting harness cables.
DC Power Jack, Part #PJ040.1
Sony
Sony PCG-FR Series: PCG-FR860, PCG-FR862, PCG-FR870, PCG-FR872
Sony PCG-FRV Series: PCG-FRV23, PCG-FRV25, PCG-FRV26, PCG-FRV27, PCG-FRV28, PCG-FRV31, PCG-FRV33, PCG-FRV34, PCG-FRV35, PCG-FRV37
Sony VGN-FJ Series: VGN-FJ150W, VGN-FJ170B, VGN-FJ170PB, VGN-FJ180PB, VGN-FJ250, VGN-FJ250P, VGN-FJ270, VGN-FJ270P, VGN-FJ290, VGN-FJ290P, VGN-FJ370
Sony VGN-CR Series: VGN-CR240E
Note: This is for the DC Jack only, you will need to reuse your exiting harness cables.
DC Power Jack, Part #PJ041
Samsung
Samsung: P40, X60
DC Power Jack, Part #PJ042
Acer
Acer: Compatible models coming soon!
DC Power Jack, Part #PJ043
Sony, Compaq
Sony: Play Station 2
Compaq: Some Docking Stations
DC Power Jack, Part #PJ044
Fujitsu Siemens
Fujitsu Siemens: Amilo 1650
DC Power Jack, Part #PJ045
Compaq, HP
Compaq Persario: V6000 Series, for 65 watt AC adapters
HP Pavilion: DV6000 and DV9000 Series, for 65 watt AC adapters
Note: If your looking for the version of this part for 90 watt AC adapters please click here for our PJ048
DC Power Jack, Part #PJ046
Fujitsu Siemens, Sony
Fujitsu Lifebook: S2000, S2010, S2020, S5582, S6110, S6120
Sony: PCG-731
DC Power Jack, Part #PJ047
Acer
Aspire: 5672WLMi
DC Power Jack, Part #PJ048
Compaq, HP
Compaq Persario: V6000 Series, for 65 watt AC adapters
HP Pavilion: DV6000 and DV9000 Series, for 90 watt AC adapters
Note: If your looking for the version of this part for 65 watt AC adapters please click here for our PJ045
This page will be updated on a regular basis so please check back
for the most up to date information.
